Panasonic Electronic Components
CAP POLYMER HYBRID 100UF 63V SMD
EEH-ZS1J101V is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP POLYMER HYBRID 100UF 63V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, voltage - rated 63 V, package / case Radial, Can - SMD.
In Stock: 4,503
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 19mOhm |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 450 mA @ 100 Hz |
| Ripple Current @ High Frequency | 3 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.516" (13.10mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| A782MS107M1JLAS030 | KEMET | CAP ALUM HYB 100UF 20% 63V SMD | 81% | View |
| HHXJ630ARA101MJA0G | Chemi-Con | CAP ALUMHYB 100UF 20% 63V SMD | 81% | View |
| GXC1J101MCW1GS | Nichicon | CAP ALUMHYB 100UF 20% 63V SMD | 80% | View |
| B40910A0117M100 | EPCOS - TDK Electronics | CAP ALUM POLY HYB 110UF 80V SMD | 75% | View |
| GYF1H101MCW1GS | Nichicon | CAP ALUMHYB 100UF 20% 50V SMD | 66% | View |
| 25PFV100M6.3X8 | Rubycon | CAP ALUM POLY HYB 100UF 25V SMD | 50% | View |
Submit your RFQ for EEH-ZS1J101V and get a quote within 24 hours.
