Panasonic Electronic Components
CAP ALUM 560UF 20% 100V SNAP
ECO-S2AA561AA is a Aluminum Electrolytic Capacitors manufactured by Panasonic Electronic Components. CAP ALUM 560UF 20% 100V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can - Snap-In.
In Stock: 9,138
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | 296mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.1 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.65 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.787" Dia (20.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
ECO-S2AA561AA is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 35ZT560M12.5X25 | Rubycon | CAP ALUM 560UF 20% 35V RADIAL | 70% | View |
| 25ZLQ560MEFC10X12.5 | Rubycon | CAP ALUM 560UF 20% 25V RADIAL | 69% | View |
| B41858C6567M000 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 50V RADIAL | 68% | View |
| EEU-FC1E561B | Panasonic Electronic Components | CAP ALUM 560UF 20% 25V RADIAL | 67% | View |
| 381LQ561M315J052 | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 315V SNAP | 66% | View |
| 16ZLQ560MEFC8X11.5 | Rubycon | CAP ALUM 560UF 20% 16V RADIAL | 53% | View |
Submit your RFQ for ECO-S2AA561AA and get a quote within 24 hours.
