Panasonic Electronic Components
CAP ALUM POLY 56UF 20% 80V T/H
80SXE56M is a Aluminum - Polymer Capacitors manufactured by Panasonic Electronic Components. CAP ALUM POLY 56UF 20% 80V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 125°C, voltage - rated 80 V, package / case Radial, Can.
In Stock: 2,596
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Polymer |
| Capacitance | 56 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | 28mOhm |
| Lifetime @ Temp. | 1000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | - |
| Applications | General Purpose |
| Features | - |
| Ripple Current @ Low Frequency | 155 mA @ 120 Hz |
| Ripple Current @ High Frequency | 3.1 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 80SXE56M+T | Panasonic Electronic Components | CAP ALUM POLY 56UF 20% 80V TH | 100% | View |
| 80SXE56M+3 | Panasonic Electronic Components | CAP ALUM POLY 56UF 20% 80V TH | 100% | View |
| 63SXE56M+S | Panasonic Electronic Components | CAP ALUM POLY 56UF 20% 63V TH | 90% | View |
| 870135674002 | Würth Elektronik | CAP ALUM POLY 56UF 20% 35V T/H | 77% | View |
| RS61E560MCN1 | Nichicon | CAP ALUM POLY 56UF 20% 25V T/H | 62% | View |
| RS61E560MCN1JT | Nichicon | CAP ALUM POLY 56UF 20% 25V T/H | 62% | View |
Submit your RFQ for 80SXE56M and get a quote within 24 hours.
