Orient Display - duplicate use 3444
LCD COB CHAR 16X2 FSTN- TRANSM
AMC1602AR-B-T6WTDY is a Display Modules - LCD, OLED Character and Numeric manufactured by Orient Display - duplicate use 3444. LCD COB CHAR 16X2 FSTN- TRANSM. Key specifications: operating temperature -20°C ~ 70°C, voltage - supply 4.5V ~ 5.5V, interface Parallel, 8-Bit, display type FSTN - Film Super-Twisted Nematic.
In Stock: 189
| Attribute | Value |
|---|---|
| Product Status | Active |
| Number of Characters | 32 |
| Display Format | 16 x 2 |
| Character Format | 5 x 8 Dots |
| Display Type | FSTN - Film Super-Twisted Nematic |
| Display Mode | Transmissive |
| Character Size | 5.55mm H x 2.95mm W |
| Outline L x W x H | 80.00mm x 36.00mm x 14.00mm |
| Viewing Area | 64.50mm L x 15.50mm W |
| Backlight | LED - Yellow/Green |
| Voltage - Supply | 4.5V ~ 5.5V |
| Dot Size | 0.55mm W x 0.65mm H |
| Interface | Parallel, 8-Bit |
| Controller Type | S6A0069 |
| Operating Temperature | -20°C ~ 70°C |
| Text Color | Yellow/Green |
| Background Color | Black |
Submit your RFQ for AMC1602AR-B-T6WTDY and get a quote within 24 hours.
