IC OFFLINE SWITCH FLYBACK 7DIP
FSQ510 is a PMIC - AC DC Converters, Offline Switchers manufactured by onsemi. IC OFFLINE SWITCH FLYBACK 7DIP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 140°C (TJ), voltage - supply (vcc/vdd) 6.7V ~ 20V, package / case 8-DIP (0.300", 7.62mm), 7 Leads.
In Stock: 6
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Flyback |
| Voltage - Start Up | 8.7 V |
| Voltage - Supply (Vcc/Vdd) | 6.7V ~ 20V |
| Duty Cycle | 60% |
| Frequency - Switching | 94.3kHz ~ 132kHz |
| Power (Watts) | 9 W |
| Fault Protection | Current Limiting, Over Load, Over Temperature |
| Control Features | Sync |
| Operating Temperature | -40°C ~ 140°C (TJ) |
| Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads |
| Supplier Device Package | 7-DIP |
| Mounting Type | Through Hole |
FSQ510 is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| FSQ510H | Fairchild Semiconductor | IC OFFLINE SWITCH FLYBACK 8DIP | 100% | View |
| TOP221P | Power Integrations | IC OFFLINE SWITCH MULT TOP 8DIP | 97% | View |
| LYT2004E | Power Integrations | IC OFFLINE SWITCH FLYBACK 7ESIP | 92% | View |
| TOP221Y | Power Integrations | IC OFFLINE SW MULT TOP TO220-3 | 89% | View |
| LNK563PG | Power Integrations | IC OFFLINE SWITCH FLYBACK 8DIP | 64% | View |
| LNK563PN | Power Integrations | IC OFFLINE SWITCH FLYBACK 8DIP | 64% | View |
Submit your RFQ for FSQ510 and get a quote within 24 hours.
