RELAY GEN PURPOSE SPST 10A 12V
G2R-1A-T DC12 is a Power Relays, Over 2 Amps manufactured by Omron Automation and Safety. RELAY GEN PURPOSE SPST 10A 12V. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 70°C, contact material Silver Alloy, termination style Quick Connect - 0.187" (4.7mm).
In Stock: 2,680
| Attribute | Value |
|---|---|
| Product Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 380VAC, 125VDC - Max |
| Coil Current | 43.6 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Quick Connect - 0.187" (4.7mm) |
| Seal Rating | Sealed - Flux Protection |
| Coil Insulation | - |
| Must Operate Voltage | 8.4 VDC |
| Must Release Voltage | 1.8 VDC |
| Operate Time | 15 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Alloy |
| Relay Type | General Purpose |
Submit your RFQ for G2R-1A-T DC12 and get a quote within 24 hours.
