RELAY GEN PURPOSE SPST 15A 24V
AZ943-1AH-24DE is a Power Relays, Over 2 Amps manufactured by American Zettler. RELAY GEN PURPOSE SPST 15A 24V. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 90°C, contact material Silver Tin Oxide (AgSnO), termination style PC Pin.
In Stock: 1,682
| Attribute | Value |
|---|---|
| Product Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 15 A |
| Switching Voltage | 277VAC, 30VDC - Max |
| Coil Current | 15 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Fully |
| Coil Insulation | Class B |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 10 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C ~ 90°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Relay Type | General Purpose |
