CAP ALUM 3.3UF 20% 200V RADIAL
UVR2D3R3MED1TA is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 3.3UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 5,774
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 3.3 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 40 mA @ 120 Hz |
| Ripple Current @ High Frequency | 64 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UVR2D3R3MED1TA is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 200LLE3.3MEFCTA6.3X11 | Rubycon | CAP ALUM 3.3UF 20% 200V RADIAL | 98% | View |
| 335TTA250M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 3.3UF 20% 250V AXIAL | 91% | View |
| 335BPA050M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 3.3UF 20% 50V AXIAL | 77% | View |
| UVR2F3R3MPA | Nichicon | CAP ALUM 3.3UF 20% 315V RADIAL | 71% | View |
| UPM2V3R3MPD1TD | Nichicon | CAP ALUM 3.3UF 20% 350V RADIAL | 69% | View |
| SEK3R3M400ST | Cornell Dubilier Electronics (CDE) | CAP ALUM 3.3UF 20% 400V RADIAL | 68% | View |
Submit your RFQ for UVR2D3R3MED1TA and get a quote within 24 hours.
