CAP ALUM 330UF 20% 16V SMD
UUQ1C331MCL6GS is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 330UF 20% 16V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can - SMD.
In Stock: 3,627
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 310 mA @ 120 Hz |
| Ripple Current @ High Frequency | 465 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UUN1E331MNJ1MS | Nichicon | CAP ALUM 330UF 20% 25V SMD | 78% | View |
| EEE-FTA331XAL | Panasonic Electronic Components | CAP ALUM 330UF 20% 10V SMD | 74% | View |
| EEV337M010A9MAA | KEMET | CAP ALUM 330UF 20% 10V SMD | 72% | View |
| 50TZV330M12.5X13.5 | Rubycon | CAP ALUM 330UF 20% 50V SMD | 56% | View |
| EMVY101GTR331MMN0S | United Chemi-Con | CAP ALUM 330UF 20% 100V SMD | 56% | View |
| EEE-FN0J331XP | Panasonic Electronic Components | CAP ALUM 330UF 20% 6.3V SMD | 54% | View |
