CAP ALUM 220UF 20% 16V SMD
UUQ1C221MCL1GS is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 220UF 20% 16V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can - SMD.
In Stock: 2,738
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 220 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 210 mA @ 120 Hz |
| Ripple Current @ High Frequency | 315 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Surface Mount Land Size | 0.327" L x 0.327" W (8.30mm x 8.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| AFK227M16X16T-F | Cornell Dubilier Electronics (CDE) | CAP ALUM 220UF 20% 16V SMD | 97% | View |
| AFK227M16E16T-F | Cornell Dubilier Electronics (CDE) | CAP ALUM 220UF 20% 16V SMD | 97% | View |
| EEE-TG1C221P | Panasonic Electronic Components | CAP ALUM 220UF 20% 16V SMD | 84% | View |
| UT227M035HFKTA | Aillen | CAP. ALUM 220UF 35V 20% SMD | 69% | View |
| EMLA100ADA221MHA0G | United Chemi-Con | CAP ALUM 220UF 20% 10V SMD | 62% | View |
| EEE-TP1V221AV | Panasonic Electronic Components | CAP ALUM 220UF 20% 35V SMD | 57% | View |
Submit your RFQ for UUQ1C221MCL1GS and get a quote within 24 hours.
