CAP ALUM 1000UF 20% 6.3V SMD
UUQ0J102MCL1GS is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1000UF 20% 6.3V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can - SMD.
In Stock: 5,084
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 310 mA @ 120 Hz |
| Ripple Current @ High Frequency | 465 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 865230157008 | Würth Elektronik | CAP ALUM 1000UF 20% 6.3V SMD | 95% | View |
| 865060153010 | Würth Elektronik | CAP ALUM 1000UF 20% 6.3V SMD | 93% | View |
| EEV108M6R3A9MAA | KEMET | CAP ALUM 1000UF 20% 6.3V SMD | 87% | View |
| EEE-FK0J102GV | Panasonic Electronic Components | CAP ALUM 1000UF 20% 6.3V SMD | 85% | View |
| EMVY100ADA102MJA0G | United Chemi-Con | CAP ALUM 1000UF 20% 10V SMD | 71% | View |
| EEE-FT1A102AL | Panasonic Electronic Components | CAP ALUM 1000UF 20% 10V SMD | 56% | View |
