CAP ALUM 4.7UF 20% 450V SMD
UUG2W4R7MNQ1ZD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 4.7UF 20% 450V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - rated 450 V, package / case Radial, Can - SMD.
In Stock: 5,708
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 4.7 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 115 mA @ 120 Hz |
| Ripple Current @ High Frequency | 184 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.571" (14.50mm) |
| Surface Mount Land Size | 0.535" L x 0.535" W (13.60mm x 13.60mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
UUG2W4R7MNQ1ZD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UUG2G4R7MNQ1ZD | Nichicon | CAP ALUM 4.7UF 20% 400V SMD | 96% | View |
| MAL215299702E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 4.7UF 20% 450V SMD | 71% | View |
| MAL219299602E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 4.7UF 20% 400V SMD | 67% | View |
| UUJ2G4R7MNQ1ZD | Nichicon | CAP ALUM 4.7UF 20% 400V SMD | 57% | View |
| AHA475M2A24B-F | Cornell Dubilier Electronics (CDE) | CAP ALUM 4.7UF 20% 100V SMD | 56% | View |
| ULV2H4R7MNL1GS | Nichicon | CAP ALUM 4.7UF 20% 500V SMD | 52% | View |
Submit your RFQ for UUG2W4R7MNQ1ZD and get a quote within 24 hours.
