CAP ALUM 470UF 20% 25V SMD
UUG1E471MNQ1ZD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 470UF 20% 25V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - rated 25 V, package / case Radial, Can - SMD.
In Stock: 5,140
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 550 mA @ 120 Hz |
| Ripple Current @ High Frequency | 825 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.571" (14.50mm) |
| Surface Mount Land Size | 0.535" L x 0.535" W (13.60mm x 13.60mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
UUG1E471MNQ1ZD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEE-TC1E471UP | Panasonic Electronic Components | CAP ALUM 470UF 20% 25V SMD | 95% | View |
| UT477M025HGKTA | Aillen | CAP. ALUM 470UF 25V 20% SMD | 79% | View |
| EEE-FP1A471AP | Panasonic Electronic Components | CAP ALUM 470UF 20% 10V SMD | 78% | View |
| EEE-FK1A471GP | Panasonic Electronic Components | CAP ALUM 470UF 20% 10V SMD | 67% | View |
| EEE-0JA471UAP | Panasonic Electronic Components | CAP ALUM 470UF 20% 6.3V SMD | 64% | View |
| EMVA500GDA471MLH0S | United Chemi-Con | CAP ALUM 470UF 20% 50V SMD | 58% | View |
Submit your RFQ for UUG1E471MNQ1ZD and get a quote within 24 hours.
