CAP ALUM 10000UF 20% 16V RADIAL
UPW1C103MHD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 10000UF 20% 16V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can.
In Stock: 9,590
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 10000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 8000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.23 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.8 A @ 100 kHz |
| Impedance | 14 mOhms |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 1.575" (40.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UPW1C103MHD is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LXZ16VB103M18X40LL | United Chemi-Con | CAP ALUM 10000UF 20% 16V RADIAL | 99% | View |
| RZW103M1CBK-1840S | Surge | CAP ALUM 16V POLAR | 94% | View |
| B41888C3109M | EPCOS - TDK Electronics | CAP ALUM 10000UF 20% 10V RADIAL | 81% | View |
| MAL213664103E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 10000UF 20% 10V RADIAL | 72% | View |
| EEU-HD1A103B | Panasonic Electronic Components | CAP ALUM 10000UF 20% 10V RADIAL | 60% | View |
| SEK103M6R3ST | Cornell Dubilier Electronics (CDE) | CAP ALUM 10000UF 20% 6.3V RADIAL | 52% | View |
