Cornell Dubilier Electronics (CDE)
CAP ALUM 10000UF 20% 6.3V RADIAL
SEK103M6R3ST is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 10000UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 1,380
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 10000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | 60mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.83 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.196 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UKT0J103MHD | Nichicon | CAP ALUM 10000UF 20% 6.3V RADIAL | 94% | View |
| EEU-FC0J103SB | Panasonic Electronic Components | CAP ALUM 10000UF 20% 6.3V RADIAL | 89% | View |
| UPA0J103MHD6 | Nichicon | CAP ALUM 10000UF 20% 6.3V RADIAL | 87% | View |
| MAL213664103E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 10000UF 20% 10V RADIAL | 69% | View |
| THAS103M016AC0C | Cornell Dubilier Electronics (CDE) | CAP ALUM 10000UF 20% 16V FLATPCK | 64% | View |
| B41888C3109M | EPCOS - TDK Electronics | CAP ALUM 10000UF 20% 10V RADIAL | 59% | View |
