CAP ALUM 560UF 20% 250V SNAP
LGR2E561MELC30 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 560UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 6,049
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.5 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.25 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MLSG561M250EB1C | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 250V FLATPACK | 100% | View |
| 381LQ561M250H452 | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 250V SNAP | 98% | View |
| 381EL561M200H452 | Cornell Dubilier Electronics (CDE) | CAP ALUM 560UF 20% 200V SNAP | 92% | View |
| LGW2D561MELZ35 | Nichicon | CAP ALUM 560UF 20% 200V SNAP | 74% | View |
| B43644B9567M060 | EPCOS - TDK Electronics | CAP ALUM 400V POLAR | 68% | View |
| B43640F5567M000 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 450V SNAP | 66% | View |
Submit your RFQ for LGR2E561MELC30 and get a quote within 24 hours.
