CAP ALUM 1500UF 20% 160V SNAP
LGG2C152MELB35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1500UF 20% 160V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 160 V, package / case Radial, Can - Snap-In.
In Stock: 1,385
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1500 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.5 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.75 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| SLP152M100E3P3 | Cornell Dubilier Electronics (CDE) | CAP ALUM 1500UF 20% 100V SNAP | 73% | View |
| 35ZLH1500MEFCG412.5X30 | Rubycon | CAP ALUM 1500UF 20% 35V RADIAL | 72% | View |
| EKMH101VSN152MA25S | United Chemi-Con | CAP ALUM 1500UF 20% 100V SNAP | 69% | View |
| EEU-TP1V152B | Panasonic Electronic Components | CAP ALUM 1500UF 20% 35V RADIAL | 64% | View |
| MAL205828152E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1500UF 20% 63V SNAP | 64% | View |
| 601D158F063GP1 | Vishay Sprague | CAP ALUM 1500UF 63V AXIAL | 63% | View |
