CAP ALUM 1000UF 20% 200V SNAP
LAR2D102MELC25 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1000UF 20% 200V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can - Snap-In.
In Stock: 1,296
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.3 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.45 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LGU2Z102MELB | Nichicon | CAP ALUM 1000UF 20% 180V SNAP | 97% | View |
| 160MXC1000MEFCSN30X30 | Rubycon | CAP ALUM 1000UF 20% 160V SNAP | 92% | View |
| 160MXC1000MEFC22X50 | Rubycon | CAP ALUM 1000UF 20% 160V SNAP | 92% | View |
| B43644F2108M002 | EPCOS - TDK Electronics | CAP ALUM 1000UF 20% 250V SNAP | 87% | View |
| B41795A8108Q001 | EPCOS - TDK Electronics | CAP ALUM 1000UF 63V T/H | 70% | View |
| MAL216259102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 100V SNAP | 69% | View |
Submit your RFQ for LAR2D102MELC25 and get a quote within 24 hours.
