CAP ALUM 100UF 20% 630V SNAP
ALC70A101CC630 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 100UF 20% 630V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 630 V, package / case Radial, Can - Snap-In.
In Stock: 1,250
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 630 V |
| ESR (Equivalent Series Resistance) | 1.29Ohm @ 100Hz |
| Lifetime @ Temp. | 13000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.18 A @ 100 Hz |
| Ripple Current @ High Frequency | 2.65 A @ 10 kHz |
| Impedance | 892 mOhms |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
Submit your RFQ for ALC70A101CC630 and get a quote within 24 hours.
