CAP ALUM POLY 47UF 20% 25V SMD
A768EB476M1ELAE042 is a Aluminum - Polymer Capacitors manufactured by KEMET. CAP ALUM POLY 47UF 20% 25V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, voltage - rated 25 V, package / case Radial, Can - SMD.
In Stock: 5,344
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Polymer |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 42mOhm |
| Lifetime @ Temp. | 2000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | - |
| Applications | General Purpose |
| Features | - |
| Ripple Current @ Low Frequency | 58.75 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.175 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Surface Mount Land Size | 0.260" L x 0.260" W (6.60mm x 6.60mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| PCX1E390MCL1GS | Nichicon | CAP ALUM POLY 39UF 20% 25V SMD | 90% | View |
| PCX1E390MCS1GS | Nichicon | CAP ALUM POLY 39UF 20% 25V SMD | 90% | View |
| PCM1V470MCL1GS | Nichicon | CAP ALUM POLY 47UF 20% 35V SMD | 89% | View |
| MAL218697501E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM POLY 47UF 20% 16V SMD | 72% | View |
| 20SVQP47M | Panasonic Electronic Components | CAP ALUM POLY 47UF 20% 20V SMD | 70% | View |
| 25SVPD39M | Panasonic Electronic Components | CAP ALUM POLY 39UF 20% 25V SMD | 66% | View |
Submit your RFQ for A768EB476M1ELAE042 and get a quote within 24 hours.
