MIC MEMS DIG PDM OMNI -26DB 4X2
GTM4020DT261SPA0 is a Microphones manufactured by GMEMS Technologies. MIC MEMS DIG PDM OMNI -26DB 4X2. Key specifications: voltage - rated 1.8 V, current - supply 800 µA, size / dimension 0.157" L x 0.079" W (4.00mm x 2.00mm), termination Solder Pads.
In Stock: 100
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10 kHz |
| Sensitivity | -26dB ±1dB |
| S/N Ratio | 64dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | 1.6 V ~ 3.6 V |
| Current - Supply | 800 µA |
| Port Location | Top |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.157" L x 0.079" W (4.00mm x 2.00mm) |
| Height (Max) | 0.043" (1.10mm) |
| Shape | Rectangular |
Submit your RFQ for GTM4020DT261SPA0 and get a quote within 24 hours.
