FIXED IND 4.7UH 5.24A 26 MOHM
B82477D4472M900 is a Arrays, Signal Transformers manufactured by EPCOS - TDK Electronics. FIXED IND 4.7UH 5.24A 26 MOHM. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C, package / case Nonstandard, size / dimension 0.492" L x 0.492" W (12.50mm x 12.50mm).
In Stock: 344
| Attribute | Value |
|---|---|
| Product Status | Active |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 4.7 µH |
| Inductance - Connected In Series | 18.8 µH |
| Tolerance | ±20% |
| Current Rating - Parallel | - |
| Current Rating - Series | 5.24 A |
| Current Saturation - Parallel | 10 A |
| Current Saturation - Series | 5 A |
| DC Resistance (DCR) - Parallel | 13mOhm Max |
| DC Resistance (DCR) - Series | 52mOhm Max |
| Shielding | Shielded |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 150°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Height | 0.335" (8.50mm) |
