CAP ALUM 270UF 20% 450V SNAP
B43652B5277M050 is a Aluminum Electrolytic Capacitors manufactured by EPCOS - TDK Electronics. CAP ALUM 270UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Snap-In.
In Stock: 5,679
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 270 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 390mOhm @ 100Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 1.54 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 590 mOhms |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43504A5277M67 | EPCOS - TDK Electronics | CAP ALUM 270UF 20% 450V SNAP | 97% | View |
| B43642A5277M002 | EPCOS - TDK Electronics | CAP ALUM 270UF 20% 450V SNAP | 93% | View |
| B43504B9277M82 | EPCOS - TDK Electronics | CAP ALUM 270UF 20% 400V SNAP | 85% | View |
| UCY2D271MHD6 | Nichicon | CAP ALUM 270UF 20% 200V RADIAL | 69% | View |
| MAL225912271E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 270UF 20% 200V SNAP | 62% | View |
| 200MXC270MEFCSN22X25 | Rubycon | CAP ALUM 270UF 20% 200V SNAP | 60% | View |
Submit your RFQ for B43652B5277M050 and get a quote within 24 hours.
