IC PWR SWITCH N-CH V-QFN4040-17
DPS1135FIA-13 is a PMIC - Power Distribution Switches, Load Drivers manufactured by Diodes Incorporated. IC PWR SWITCH N-CH V-QFN4040-17. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), voltage - supply (vcc/vdd) Not Required, package / case 17-VFQFN Exposed Pad.
In Stock: 8,593
| Attribute | Value |
|---|---|
| Product Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 4.5V ~ 24V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 5A |
| Rds On (Typ) | 30mOhm |
| Input Type | Non-Inverting |
| Features | Load Discharge, Slew Rate Controlled, Status Flag |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Current, Short Circuit, UVLO |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | V-QFN4040-17 |
| Package / Case | 17-VFQFN Exposed Pad |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| IPS1025HTR-32 | STMicroelectronics | IPS1025 | 100% | View |
| IPS1025H | STMicroelectronics | IPS1025H | 100% | View |
| TPS2557QDRBRQ1 | Texas Instruments | IC PWR SWITCH N-CHAN 1:1 8SON | 90% | View |
| BTS70202EPAXUMA1 | Infineon Technologies | IC PWR SWTCH N-CHAN 1:1 TSDSO-14 | 83% | View |
| BTS50202EKAXUMA2 | Infineon Technologies | IC PWR SWITCH N-CHAN 1:1 DSO-14 | 77% | View |
| MP5016HGQH-P | Monolithic Power Systems Inc. | IC PWR SWITCH N-CHAN 1:1 10QFN | 72% | View |
