FAN AXIAL 92X15MM 12VDC WIRE
AFB0912HHB-F00 is a DC Brushless Fans (BLDC) manufactured by Delta Electronics. FAN AXIAL 92X15MM 12VDC WIRE. Key specifications: operating temperature 14 ~ 140°F (-10 ~ 60°C), voltage - rated 12VDC, size / dimension Square - 92mm L x 92mm H, termination 3 Wire Leads.
In Stock: 438
| Attribute | Value |
|---|---|
| Product Status | Active |
| Voltage - Rated | 12VDC |
| Size / Dimension | Square - 92mm L x 92mm H |
| Width | 15.00mm |
| Air Flow | 51.3 CFM (1.44m³/min) |
| Static Pressure | 0.156 in H2O (38.8 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection, Speed Sensor (Tach) |
| Noise | 41.5dB(A) |
| Power (Watts) | 3.72 W |
| RPM | 3300 RPM |
| Termination | 3 Wire Leads |
| Ingress Protection | - |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Approval Agency | CE, CSA, UL, VDE |
| Weight | 0.154 lb (69.85 g) |
Submit your RFQ for AFB0912HHB-F00 and get a quote within 24 hours.
