Cornell Dubilier Electronics (CDE)
CAP ALUM 680UF 20% 220V SNAP
SLP681M220E5P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 680UF 20% 220V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 220 V, package / case Radial, Can - Snap-In.
In Stock: 2,214
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 680 µF |
| Tolerance | ±20% |
| Voltage - Rated | 220 V |
| ESR (Equivalent Series Resistance) | 293mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.93 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.84 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.378" (35.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LGG2D681MELA30 | Nichicon | CAP ALUM 680UF 20% 200V SNAP | 89% | View |
| LGU2C681MELB | Nichicon | CAP ALUM 680UF 20% 160V SNAP | 88% | View |
| 381LX681M180J042 | Cornell Dubilier Electronics (CDE) | CAP ALUM 680UF 20% 180V SNAP | 87% | View |
| 381LR681M250K032 | Cornell Dubilier Electronics (CDE) | CAP ALUM 680UF 20% 250V SNAP | 86% | View |
| LKX2G681MESC50 | Nichicon | CAP ALUM 680UF 20% 400V SNAP | 78% | View |
| B43504A9687M000 | EPCOS - TDK Electronics | CAP ALUM 680UF 20% 400V SNAP | 66% | View |
