Cornell Dubilier Electronics (CDE)
CAP ALUM 2200UF 20% 80V SNAP
SLP222M080E1P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 2200UF 20% 80V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 80 V, package / case Radial, Can - Snap-In.
In Stock: 6,040
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 2200 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | 151mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.98 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.48 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LSM222M1K---3525S | Surge | CAP ALUM 80V POLAR | 95% | View |
| B41252A8228M000 | EPCOS - TDK Electronics | CAP ALUM 2200UF 20% 63V SNAP | 88% | View |
| KMH63VN222M25X30T2 | United Chemi-Con | CAP ALUM 2200UF 20% 63V SNAP | 86% | View |
| UBY1H222MHL | Nichicon | CAP ALUM 2200UF 20% 50V RADIAL | 76% | View |
| UHE1C222MHT6 | Nichicon | CAP ALUM 2200UF 20% 16V RADIAL | 73% | View |
| UPJ1C222MHD6CA | Nichicon | CAP ALUM 16V POLAR | 72% | View |
Submit your RFQ for SLP222M080E1P3 and get a quote within 24 hours.
