Cornell Dubilier Electronics (CDE)
CAP ALUM 15000UF 20% 10V SNAP
SLP153M010A5P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 15000UF 20% 10V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 10 V, package / case Radial, Can - Snap-In.
In Stock: 1,248
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 10 V |
| ESR (Equivalent Series Resistance) | 49mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.3 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.88 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.378" (35.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 16VXG15000MEFCSN30X30 | Rubycon | CAP ALUM 15000UF 20% 16V SNAP | 83% | View |
| LGU1C153MELB | Nichicon | CAP ALUM 15000UF 20% 16V SNAP | 82% | View |
| EKZN100ELL153MM40S | United Chemi-Con | CAP ALUM 15000UF 20% 10V RADIAL | 72% | View |
| 6.3YXG15000MEFCGC18X35.5 | Rubycon | CAP ALUM 15000UF 20% 6.3V RADIAL | 71% | View |
| LGY1E153MELB35 | Nichicon | CAP ALUM 15000UF 20% 25V SNAP | 70% | View |
| EKYB6R3ELL153MLP1S | United Chemi-Con | CAP ALUM 15000UF 20% 6.3V RADIAL | 68% | View |
Submit your RFQ for SLP153M010A5P3 and get a quote within 24 hours.
