Cornell Dubilier Electronics (CDE)
CAP ALUM 33UF 20% 50V SMD
AVEK336M50F24T-F is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 33UF 20% 50V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can - SMD.
In Stock: 1,198
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 6Ohm @ 120Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 178 mA @ 120 Hz |
| Ripple Current @ High Frequency | 267 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | 0.331" L x 0.331" W (8.40mm x 8.40mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
AVEK336M50F24T-F is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEE-FK1H330P | Panasonic Electronic Components | CAP ALUM 33UF 20% 50V SMD | 88% | View |
| AFK336M35D16T-F | Cornell Dubilier Electronics (CDE) | CAP ALUM 33UF 20% 35V SMD | 86% | View |
| UCL1E330MCL6GS | Nichicon | CAP ALUM 33UF 20% 25V SMD | 67% | View |
| UT336M100HGKTA | Aillen | CAP. ALUM 33UF 100V 20% SMD | 63% | View |
| AFK336M25C12T-F | Cornell Dubilier Electronics (CDE) | CAP ALUM 33UF 20% 25V SMD | 57% | View |
| EEV336M016A9DAA | KEMET | CAP ALUM 33UF 20% 16V SMD | 56% | View |
