Cornell Dubilier Electronics (CDE)
CAP ALUM 22UF 20% 35V SMD
AFK226M35C12T-F is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 22UF 20% 35V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can - SMD.
In Stock: 5,876
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | 700mOhm @ 100kHz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive, Bypass, Decoupling |
| Ripple Current @ Low Frequency | 120 mA @ 120 Hz |
| Ripple Current @ High Frequency | 160 mA @ 100 kHz |
| Impedance | 700 mOhms |
| Lead Spacing | - |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.240" (6.10mm) |
| Surface Mount Land Size | 0.209" L x 0.256" W (5.30mm x 6.50mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EXV226M035A9DAA | KEMET | CAP ALUM 22UF 20% 35V SMD | 94% | View |
| UZ226M025HDHTA | Aillen | CAP ALUM 22UF 20% 25V SMD | 89% | View |
| EEE-FK1J220XL | Panasonic Electronic Components | CAP ALUM 22UF 20% 63V SMD | 66% | View |
| UUX1H220MCL6GS | Nichicon | CAP ALUM 22UF 20% 50V SMD | 64% | View |
| EEE-FN1H220UR | Panasonic Electronic Components | CAP ALUM 22UF 20% 50V SMD | 55% | View |
| AEK0810220M100R | KYOCERA AVX | AEK/0810/220/100V | 52% | View |
