IPC0089-S
DFN-22 STENCIL
IPC0089-S is a Solder Stencils, Templates manufactured by Chip Quik Inc.. DFN-22 STENCIL. Key specifications: material Stainless Steel, number of positions 22, pitch 0.020" (0.50mm).
In Stock: 8,387
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | DFN |
| Number of Positions | 22 |
| Pitch | 0.020" (0.50mm) |
| Outer Dimension | 1.300" L x 0.900" W (33.02mm x 22.86mm) |
| Inner Dimension | 0.236" L x 0.197" W (6.00mm x 5.00mm) |
| Thermal Center Pad | 0.213" L x 0.102" W (5.40mm x 2.60mm) |
| Material | Stainless Steel |
Frequently Asked Questions
IPC0089-S is a Solder Stencils, Templates manufactured by Chip Quik Inc.. DFN-22 STENCIL
The material of IPC0089-S is Stainless Steel.
The number of positions of IPC0089-S is 22.
The pitch of IPC0089-S is 0.020" (0.50mm).
