IPC0023-S
QFN-32 STENCIL
IPC0023-S is a Solder Stencils, Templates manufactured by Chip Quik Inc.. QFN-32 STENCIL. Key specifications: material Stainless Steel, number of positions 32, pitch 0.031" (0.80mm).
In Stock: 4,799
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | QFN/LFCSP |
| Number of Positions | 32 |
| Pitch | 0.031" (0.80mm) |
| Outer Dimension | 1.300" L x 0.900" W (33.02mm x 22.86mm) |
| Inner Dimension | 0.315" L x 0.315" W (8.00mm x 8.00mm) |
| Thermal Center Pad | 0.228" L x 0.228" W (5.80mm x 5.80mm) |
| Material | Stainless Steel |
Frequently Asked Questions
IPC0023-S is a Solder Stencils, Templates manufactured by Chip Quik Inc.. QFN-32 STENCIL
The material of IPC0023-S is Stainless Steel.
The number of positions of IPC0023-S is 32.
The pitch of IPC0023-S is 0.031" (0.80mm).
