28X28 MM SPEAKER
BLS2828-12-08H11 is a Speakers manufactured by BeStar Technologies, Inc.. 28X28 MM SPEAKER. Key specifications: size / dimension 1.102" L x 1.102" W (28.00mm x 28.00mm), termination Solder Pads, power - max 2.5 W, frequency range 0 Hz ~ 20 kHz.
In Stock: 50
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Magnetic |
| Type | General Purpose |
| Frequency Range | 0 Hz ~ 20 kHz |
| Frequency - Self Resonant | 400Hz |
| Impedance | 8 Ohms |
| Efficiency - dBA | 84.00 |
| Efficiency - Testing | 100mW/100mm |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Power - Rated | 2 W |
| Power - Max | 2.5 W |
| Port Location | Top |
| Shape | Square |
| Material - Cone | Polyester, Polyethylene Terephthalate (PET) |
| Material - Magnet | Nd-Fe-B |
| Ingress Protection | - |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 1.102" L x 1.102" W (28.00mm x 28.00mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
