DC DC CONVERTER 25-90V 100MW
SIP90 is a DC DC Converters manufactured by XP Power. DC DC CONVERTER 25-90V 100MW. Key specifications: mounting type Through Hole, operating temperature -20°C ~ 70°C, package / case 5-SIP Module, current - output (max) 1mA.
In Stock: 15
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | High Voltage - Non-Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 3V |
| Voltage - Input (Max) | 6.7V |
| Voltage - Output 1 | 25 ~ 90V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1mA |
| Power (Watts) | 100 mW |
| Voltage - Isolation | - |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -20°C ~ 70°C |
| Efficiency | - |
| Mounting Type | Through Hole |
| Package / Case | 5-SIP Module |
| Size / Dimension | 1.15" L x 0.16" W x 0.55" H (29.2mm x 4.1mm x 14.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
