DC DC CONVERTER -1250V 1W
CA12N-5 is a DC DC Converters manufactured by XP Power. DC DC CONVERTER -1250V 1W. Key specifications: mounting type Through Hole, operating temperature -10°C ~ 50°C, package / case 8-DIP Module, current - output (max) 800µA.
In Stock: 80
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | High Voltage - Non-Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.75V |
| Voltage - Input (Max) | 5.25V |
| Voltage - Output 1 | -1250V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 800µA |
| Power (Watts) | 1 W |
| Voltage - Isolation | - |
| Applications | ITE (Commercial) |
| Features | SCP |
| Operating Temperature | -10°C ~ 50°C |
| Efficiency | - |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP Module |
| Size / Dimension | 1.75" L x 1.10" W x 0.50" H (44.5mm x 27.9mm x 12.7mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | 62368-1 |
