FIXED IND 4.7UH 12.2A 8.2MOHM SM
7843320470 is a Fixed Inductors manufactured by Würth Elektronik. FIXED IND 4.7UH 12.2A 8.2MOHM SM. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C, package / case Nonstandard, current rating (amps) 12.2 A.
In Stock: 206
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 12.2 A |
| Current - Saturation (Isat) | 15.3A |
| Shielding | Shielded |
| DC Resistance (DCR) | 8.2mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 37MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 150°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | 1212 |
| Size / Dimension | 0.480" L x 0.480" W (12.20mm x 12.20mm) |
| Height - Seated (Max) | 0.474" (12.05mm) |
Submit your RFQ for 7843320470 and get a quote within 24 hours.
