INDUCT ARRAY 2 COIL 15UH SMD
7448990150 is a Arrays, Signal Transformers manufactured by Würth Elektronik. INDUCT ARRAY 2 COIL 15UH SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case Nonstandard, size / dimension 0.453" L x 0.394" W (11.50mm x 10.00mm).
In Stock: 300
| Attribute | Value |
|---|---|
| Product Status | Active |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 15 µH |
| Inductance - Connected In Series | - |
| Tolerance | ±20% |
| Current Rating - Parallel | 3.9 A |
| Current Rating - Series | - |
| Current Saturation - Parallel | 9.5 A |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Parallel | 87mOhm |
| DC Resistance (DCR) - Series | - |
| Shielding | Shielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.453" L x 0.394" W (11.50mm x 10.00mm) |
| Height | 0.354" (9.00mm) |
Submit your RFQ for 7448990150 and get a quote within 24 hours.
