INDUCT ARRAY 2 COIL 1UH SMD
7448841010 is a Arrays, Signal Transformers manufactured by Würth Elektronik. INDUCT ARRAY 2 COIL 1UH SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case Nonstandard, size / dimension 0.205" L x 0.205" W (5.20mm x 5.20mm).
In Stock: 1,275
| Attribute | Value |
|---|---|
| Product Status | Active |
| Number of Coils | 2 |
| Inductance - Connected In Parallel | 1 µH |
| Inductance - Connected In Series | - |
| Tolerance | ±30% |
| Current Rating - Parallel | 2.9 A |
| Current Rating - Series | - |
| Current Saturation - Parallel | 5 A |
| Current Saturation - Series | - |
| DC Resistance (DCR) - Parallel | 45mOhm |
| DC Resistance (DCR) - Series | - |
| Shielding | Shielded |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.205" L x 0.205" W (5.20mm x 5.20mm) |
| Height | 0.122" (3.10mm) |
