1-CONDUCTOR FEMALE PLUG; 100% PR
2734-202/037-000 is a Terminal Blocks - Headers, Plugs and Sockets manufactured by WAGO Corporation. 1-CONDUCTOR FEMALE PLUG; 100% PR. Key specifications: mounting type Free Hanging (In-Line), operating temperature -60°C ~ 100°C, color Orange, termination style Screwless - Push-In Spring.
In Stock: 5,543
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Plug, Female Sockets |
| Number of Positions | 2 |
| Positions Per Level | 2 |
| Number of Levels | 1 |
| Pitch | 0.150" (3.81mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screwless - Push-In Spring |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 10A |
| Voltage - IEC | 320 V |
| Current - UL | 10 A |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG | 16-24 AWG |
| Wire Gauge or Range - mm² | 0.2-1.5mm² |
| Color | Orange |
| Operating Temperature | -60°C ~ 100°C |
| Contact Mating Finish | Tin |
| Features | Lever Actuated, Retention Latches (Non-Wire Side) |
Submit your RFQ for 2734-202/037-000 and get a quote within 24 hours.
