Vishay Beyschlag/Draloric/BC Components
CAP ALUM 1500UF 20% 400V SNAP
MAL229966152E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 1500UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 4,817
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1500 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 90mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 5.2 A @ 100 Hz |
| Ripple Current @ High Frequency | 7.8 A @ 10 kHz |
| Impedance | 70 mOhms |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.772" Dia (45.00mm) |
| Height - Seated (Max) | 2.835" (72.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| E91D401VNT152MU80U | Chemi-Con | CAP ALUM 400V POLAR | 98% | View |
| E93E401VNT152MU80U | Chemi-Con | CAP ALUM 400V POLAR | 98% | View |
| 200MXC1500MEFCSN30X50 | Rubycon | CAP ALUM 1500UF 20% 200V SNAP | 54% | View |
| HVMLS152M060EK1C | Cornell Dubilier Electronics (CDE) | CAP ALUM 1500UF 20% 60V FLATPACK | 54% | View |
| LGN2E152MELC45 | Nichicon | CAP ALUM 1500UF 20% 250V SNAP | 51% | View |
| 158RZM035M1340 | Cornell Dubilier / Illinois Capacitor | CAP ALUM 1500UF 20% 35V RADIAL | 50% | View |
