Vishay Beyschlag/Draloric/BC Components
CAP ALUM 560UF 20% 400V SNAP
MAL229956561E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 560UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 7,017
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 220mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.7 A @ 100 Hz |
| Ripple Current @ High Frequency | 4.05 A @ 10 kHz |
| Impedance | 160 mOhms |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 2.047" (52.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43601B9567M87 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 400V SNAP | 100% | View |
| B43305A2567M67 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 200V SNAP | 77% | View |
| EEE-HAC471UAP | Panasonic Electronic Components | CAP ALUM 470UF 20% 16V SMD | 75% | View |
| 500D477M040EF2A | Vishay Sprague | CAP ALUM 470UF 20% 40V AXIAL | 75% | View |
| KMQ160VS471M22X25T2 | United Chemi-Con | CAP ALUM 470UF 20% 160V SNAP | 75% | View |
| B43305A2687M60 | EPCOS - TDK Electronics | CAP ALUM 680UF 20% 200V SNAP | 72% | View |
