Vishay Beyschlag/Draloric/BC Components
CAP ALUM 1800UF 20% 400V SNAP
MAL229956182E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 1800UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 5,855
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 70mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 6.02 A @ 100 Hz |
| Ripple Current @ High Frequency | 9.03 A @ 10 kHz |
| Impedance | 50 mOhms |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Height - Seated (Max) | 4.016" (102.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 380LX182M100J032 | Cornell Dubilier Electronics (CDE) | CAP ALUM 1800UF 20% 100V SNAP | 100% | View |
| E32D501CDN182ME79U | United Chemi-Con | CAP ALUM 1800UF 20% 500V SCREW | 100% | View |
| ELXS251VSN152MA45S | United Chemi-Con | CAP ALUM 1500UF 20% 250V SNAP | 74% | View |
| B43508E2158M67 | EPCOS - TDK Electronics | CAP ALUM 1500UF 20% 250V SNAP | 74% | View |
| B43657C5158M057 | EPCOS - TDK Electronics | CAP ALUM 450V POLAR | 74% | View |
| UFG1E222MHM | Nichicon | CAP ALUM 2200UF 20% 25V RADIAL | 71% | View |
Submit your RFQ for MAL229956182E3 and get a quote within 24 hours.
