Vishay Beyschlag/Draloric/BC Components
CAP ALUM 56UF 20% 500V SNAP
MAL225959569E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 56UF 20% 500V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 500 V, package / case Radial, Can - Snap-In.
In Stock: 8,409
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 56 µF |
| Tolerance | ±20% |
| Voltage - Rated | 500 V |
| ESR (Equivalent Series Resistance) | 2.31Ohm @ 100Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 670 mA @ 100 Hz |
| Ripple Current @ High Frequency | 1.005 A @ 10 kHz |
| Impedance | 1.7 Ohms |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKHE451ELL560MK35S | United Chemi-Con | RADIAL ALUMINUM ELECTROLYTIC CAP | 88% | View |
| 450BXW56MEFR12.5X45 | Rubycon | CAP ALUM 56UF 20% 450V RADIAL | 85% | View |
| 450BXW56MEFR16X30 | Rubycon | CAP ALUM 56UF 20% 450V RADIAL | 85% | View |
| 400HXW56MEFR10X35 | Rubycon | CAP ALUM 56UF 20% 400V RADIAL | 83% | View |
| EKXJ421ELL560MK45S | United Chemi-Con | CAP ALUM 56UF 20% 420V RADIAL | 82% | View |
| 420BXW56MEFR12.5X35 | Rubycon | CAP ALUM 56UF 20% 420V RADIAL | 82% | View |
Submit your RFQ for MAL225959569E3 and get a quote within 24 hours.
