Vishay Beyschlag/Draloric/BC Components
CAP ALUM 560UF 20% 250V SNAP
MAL225933561E3 is a Aluminum Electrolytic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM 560UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 5,861
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | 210mOhm @ 100Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.24 A @ 100 Hz |
| Ripple Current @ High Frequency | 3.36 A @ 10 kHz |
| Impedance | 140 mOhms |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LGW2E561MELZ45 | Nichicon | CAP ALUM 560UF 20% 250V SNAP | 100% | View |
| LGU2P561MELB | Nichicon | CAP ALUM 560UF 20% 220V SNAP | 83% | View |
| B43504B2567M2 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 250V SNAP | 82% | View |
| B43508G2567M87 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 250V SNAP | 77% | View |
| EEU-FM1H561 | Panasonic Electronic Components | CAP ALUM 560UF 20% 50V RADIAL | 61% | View |
| ALC80C561EF450 | KEMET | CAP ALUM 560UF 20% 450V SNAP | 59% | View |
