Vishay Beyschlag/Draloric/BC Components
CAP ALUM POLY 120UF 20% 20V SMD
MAL218597553E3 is a Aluminum - Polymer Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. CAP ALUM POLY 120UF 20% 20V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 20 V, package / case Radial, Can - SMD.
In Stock: 8,128
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Polymer |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 20 V |
| ESR (Equivalent Series Resistance) | 33mOhm |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | - |
| Applications | General Purpose |
| Features | - |
| Ripple Current @ Low Frequency | 145 mA @ 120 Hz |
| Ripple Current @ High Frequency | 2.9 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.315" (8.00mm) |
| Surface Mount Land Size | 0.335" L x 0.335" W (8.50mm x 8.50mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| APXS160ARA121MH70G | United Chemi-Con | CAP ALUM POLY 120UF 20% 16V SMD | 91% | View |
| PCX1E121MCL6GS | Nichicon | CAP ALUM POLY 120UF 20% 25V SMD | 82% | View |
| A765EB127M1ALAE018 | KEMET | CAP ALUM POLY 120UF 20% 10V SMD | 79% | View |
| 10SVP120M | Panasonic Electronic Components | CAP ALUM POLY 120UF 20% 10V SMD | 73% | View |
| 875075655005 | Würth Elektronik | CAP ALUM POLY 120UF 20% 35V SMD | 70% | View |
| APXE6R3ARA121ME61G | United Chemi-Con | CAP ALUM POLY 120UF 20% 6.3V SMD | 67% | View |
Submit your RFQ for MAL218597553E3 and get a quote within 24 hours.
