Vishay Beyschlag/Draloric/BC Components
715C 50KVDC 1000PF 20% N4700 743
715C50KTD10M5 is a Ceramic Capacitors manufactured by Vishay Beyschlag/Draloric/BC Components. 715C 50KVDC 1000PF 20% N4700 743. Key specifications: mounting type Requires Holder, operating temperature -30°C ~ 85°C, voltage - rated 50000V (50kV), package / case Disk, Metal Fitting - Threaded.
In Stock: 40
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 pF |
| Tolerance | ±20% |
| Voltage - Rated | 50000V (50kV) |
| Temperature Coefficient | N4700 |
| Operating Temperature | -30°C ~ 85°C |
| Features | High Voltage, Low Dissipation Factor |
| Ratings | - |
| Applications | General Purpose |
| Failure Rate | - |
| Mounting Type | Requires Holder |
| Package / Case | Disk, Metal Fitting - Threaded |
| Size / Dimension | 1.890" Dia x 1.378" L (48.00mm x 35.00mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | - |
| Lead Spacing | - |
| Lead Style | - |
