CAP ALUM 1000UF 20% 20V RADIAL
678D108M020DT4J is a Aluminum Electrolytic Capacitors manufactured by Vishay Sprague. CAP ALUM 1000UF 20% 20V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 20 V, package / case Radial, Can.
In Stock: 8,989
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 20 V |
| ESR (Equivalent Series Resistance) | 115mOhm @ 20Hz |
| Lifetime @ Temp. | - |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 546 mA @ 120 Hz |
| Ripple Current @ High Frequency | 780 mA @ 100 kHz |
| Impedance | 45 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.346" (34.20mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 25PX1000MEFCT810X16 | Rubycon | CAP ALUM 1000UF 20% 25V RADIAL | 83% | View |
| MAL214665102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 16V RADIAL | 75% | View |
| MAL211816102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 25V AXIAL | 71% | View |
| 35WXA1000MEFCGC16X16 | Rubycon | CAP ALUM 1000UF 20% 35V RADIAL | 66% | View |
| UPA1A102MPD | Nichicon | CAP ALUM 1000UF 20% 10V RADIAL | 62% | View |
| MAL215060102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 35V RADIAL | 51% | View |
Submit your RFQ for 678D108M020DT4J and get a quote within 24 hours.
