CAP ALUM 68UF 100V RADIAL
672D686H100ET5JSR1 is a Aluminum Electrolytic Capacitors manufactured by Vishay Sprague. CAP ALUM 68UF 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 5,534
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 68 µF |
| Tolerance | - |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | - |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.417" (36.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPM2A680MHD6TO | Nichicon | CAP ALUM 68UF 20% 100V RADIAL | 100% | View |
| MAL213669689E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 68UF 20% 100V RADIAL | 100% | View |
| MALREKB05DD268L00K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 68UF 20% 100V RADIAL | 100% | View |
| MALREKB00DD268L00K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 68UF 20% 100V RADIAL | 100% | View |
| UBX1J680MPL1TD | Nichicon | CAP ALUM 68UF 20% 63V RADIAL | 70% | View |
| EEU-FC1H680 | Panasonic Electronic Components | CAP ALUM 68UF 20% 50V RADIAL | 56% | View |
Submit your RFQ for 672D686H100ET5JSR1 and get a quote within 24 hours.
