CAP ALUM 220UF 40V RADIAL
672D227F040EK5J is a Aluminum Electrolytic Capacitors manufactured by Vishay Sprague. CAP ALUM 220UF 40V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 40 V, package / case Radial, Can.
In Stock: 1,755
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 220 µF |
| Tolerance | -10%, +50% |
| Voltage - Rated | 40 V |
| ESR (Equivalent Series Resistance) | 480mOhm @ 120Hz |
| Lifetime @ Temp. | - |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.155 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.65 A @ 100 kHz |
| Impedance | 120 mOhms |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.098" (27.90mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL216051221E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 220UF 20% 50V RADIAL | 81% | View |
| UPJ1J221MHD | Nichicon | CAP ALUM 220UF 20% 63V RADIAL | 71% | View |
| MAL214630221E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 220UF 20% 35V RADIAL | 69% | View |
| RXK221M1VBK-1016S | SURGE | CAP ALUM 220UF 20% 35V RADIAL | 63% | View |
| EJ1H221MP51013RU | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 59% | View |
| ELXZ350ETC221MH15D | United Chemi-Con | CAP ALUM 220UF 20% 35V RADIAL | 53% | View |
