IHTH-1500TZ-5A 33 20% EB E2
IHTH1500TZEB330M5A is a Fixed Inductors manufactured by Vishay Dale. IHTH-1500TZ-5A 33 20% EB E2. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 155°C, package / case Radial, Vertical Cylinder, 4 Leads, current rating (amps) 28.7 A.
In Stock: 1
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | - |
| Material - Core | Metal Composite |
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 28.7 A |
| Current - Saturation (Isat) | 56.6A |
| Shielding | Shielded |
| DC Resistance (DCR) | 5.1mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 2.6MHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder, 4 Leads |
| Supplier Device Package | Radial |
| Size / Dimension | 1.500" Dia (38.10mm) |
| Height - Seated (Max) | 0.780" (19.82mm) |
Submit your RFQ for IHTH1500TZEB330M5A and get a quote within 24 hours.
